Daylight View Technology |
 |
Wireless AV Streaming |
|
 |
Multi-User Screen |
 |
Direct Power Off |
 |
 |
||||
| MODEL | PT-LB60NTE | PT-LB55NTE | PT-LB50NTE | PT-AE900E | |
| LCD PANEL | Panel Size | 0.8" | 0.7" | 0.6" | 0.7" |
| Brightness | 3200 lumens | 2500 lumens | 2000 lumens | 1100 lumens | |
| Contrast | 400:1 | 5500:1 | |||
| Native Resolution | 1024 x 768 (4:3) | 1280 x 720 (16:9) | |||
| Colours | 16.7M | 1070M; | |||
| COMMS | Wireless | 802.11b/g | n/a | ||
| PROJECTION | Projection Size | 33-300" (838-7620mm) diagonally, 4:3 | 40-300" (1016-7620mm) diagonally, 16:9 | ||
| Throw Distance | 3'7" - 35'5" (1.1m - 10.8m) |
3'11" - 39'4" (1.2m - 12.0m) |
3'7" - 36'5" (1.1m - 11.1m) |
||
| POWER | Consumption | 300W | 300W | 240W | 180W |
| Voltage | AC100-240V, 50/60Hz | ||||
| I/O PORT | Rear Terminals |
PC1-In PC2-In / PC1-Out Video-In SVideo-In Audio-In Audio-Out Serial |
(1x Dsub15) (1x Dsub15) (1x RCA pin) (1x Mini DIN 4-pin) (2x RCA L/R (Video/SVideo only)) (1x M3 Stereo (PC1-In)) (1x M3 Stereo (PC2-In)) (1x M3 Stereo) (1x Mini DIN 8-pin, RS232C) |
HDMI-In (1x 19pin) PC-In (1x Dsub15) Component (3x RCA) Video-In (1x RCA) SVideo-In (1x Mini DIN) Serial (Mini DIN) |
|
| PACKAGE | Unit WxHxD (mm) | 327 x 75 x 233 | 327 x 75 x 233 | 297 x 57 x 210 | 335 x 95 x 270 |
| Box WxHxD (mm) | |||||
| Weight (Net) | 2.6Kg | 2.6Kg | 1.9Kg | 3.6Kg | |
| Weight (Gross) | |||||
| Box Contents | Power Cord, Remote Control, Batteries for Remote Control, VGA Cable, Lens Cover, Carry Bag, Software | Power Cord, Remote Control, Batteries for Remote Control | |||
| BROCHURE | Download Brochure (287KB) |
Download Brochure (278KB) |
Download Brochure (1.22MB) |
||
| Compatibilty: | |||||
| OPTIONS | ET-LAB30 Replacement Lamp |
 |
|
|
 |
| ET-LAE900 Replacement Lamp |
|
|
|
|
|
| ET-PKB30 Ceiling Mount Bracket |
|
|
|
|
|
| ET-PKE300/700 Ceiling Mount Bracket |
|
|
|
|
|
| ET-RM300 Full Remote |
|
|
|
|
|
| ET-ADSER Serial Adapter |
|
|
|
|
|
| All information is subject to change without notice | |||||
